Shandong Craier Environmental Technology Co., Ltd.
ULP-4040 RO membrane
Keywords : 2540
Classification :
PRODUCT DETAILS
1. ULP- 4040 series, the membrane effective area is 10 square meters, the water production capacity is 0.25T/H, the water inlet pressure is 150psi.
2. The biggest feature of this low-pressure membrane is high water production and low energy consumption.
3. It is mainly used in brackish water, tap water, and groundwater ，But,with a salt content below 1500 milligrams.
4. The main operating pressure is around 10 kilograms, with a desalination rate of over 99% and a service life of about 3 years.
| Model | ULP-80-400 | ULP-4040 |
| Dimensions | 8inch | 4inch |
| Membrane material | Aromatic polyamide composites | |
| Effective membrane area | 400（37.2） | 85（7.9） |
| Inlet screen thickness | 32mil | |
| Desalination rate | Average | 99.30% |
| Lowest | 99.10% | |
| Water output | 11500gpd (43.5m³/d) | 2600gpd (9.2m³/d) |
| NaCL solution concentration, mg/L | 1500 | |
| Pressure, psi (MPa) | 150(1.0) | |
| Temperature, °C | 25 | |
| Recovery rate of single membrane element, % | 15 | |
| Test solution pH | 6.5-7.0 | |
| Maximum inlet pressure, psi (MPa) | 600PSI(4.14) | |
| Maximum inlet temperature, °C | 45 | |
| Inlet pH range | 2-10 | |
| Cleaning PH range | 1-10 | |
| Maximum inlet turbidity, NTU | 1.0 | |
| Maximum inlet SDI | <3 | |
| Maximum inlet residual chlorine concentration, mg/L | <0.1 | |
| Minimum ratio of concentrated water to water output | 5;1 | |
| Maximum pressure drop of single element, psi (MPa) | 10(0.07) | |
Q1: Can I get some samples?
A: Yes, sample order is available for quality check and market test. But you have to pay the sample cost and express cost.
Q2: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.
Q3: What's the lead time？
A: According to the order quantity, small order usually need 3-5 days, big order need negotiation.
Q4: What's your warranty terms?
A: We supply 18 months warranty time.
Q5: What's your payment terms?
A: We receive Escrow, T/T, West Union, Cash and etc.
