LP-8040 Ro membrane

1. LP-8040 membrane for Well water, groundwater, tap water, with a salt content below 3000 2. 10-25days deliver goods 3. MOQ=10PCS

Keywords : 2540

Classification :

E-mail

PRODUCT DETAILS

1. LP-8040 series, Firstly, in terms of effective membrane area, it is 40 or 44 square meters

2. When the conductivity is 1000, the water production of a single membrane is more than 1 ton per hour.

3. The biggest feature of this low-pressure membrane is high water production and low energy consumption.

4. It is mainly used in brackish water, tap water, and groundwater ，But,with a salt content below 3000 milligrams.

5. The main operating pressure is around 10-15 kilograms, with a desalination rate of over 99% and a service life of about 3 years.

Model	LP-8040	LP-4040
Dimensions	8inch	4inch
Membrane material	Aromatic polyamide composites
Effective membrane area	400（37.2）	85（7.9）
Inlet screen thickness	32mil
Desalination rate	Average	99.50%
	Lowest	99.30%
Water output	10500gpd (40m³/d)	2600gpd (9.2m³/d)
NaCL solution concentration, mg/L	2000
Pressure, psi (MPa)	225(15.5)
Temperature, °C	25
Recovery rate of single membrane element, %	15
Test solution pH	6.5-7.0
Maximum inlet pressure, psi (MPa)	600PSI(4.14)
Maximum inlet temperature, °C	45
Inlet pH range	2-10
Cleaning DH range	1-12
Maximum inlet turbidity, NTU	1.0
Maximum inlet SDI	<5
Maximum inlet residual chlorine concentration, mg/L	<0.1
Minimum ratio of concentrated water to water output	5;1
Maximum pressure drop of single element, psi (MPa)	10(0.07)
